主要用途
適用于塊、球、果實類植物藥如：澤瀉、川芎、白術等切成2~6mm薄片。
Main uses
suitable to cut lump, fruit herb such as Atractylodes and Alisma into pieces from 2 mm to 6 mm.
主要特點
連續作業、片形好、效率高，轉子可無級調速，可配防粘刀裝置，易操作，維修方便，符合GMP要求。
Main technical characteristics
The machine is very efficient and can work continuously. The roller is continuously variable and in addition there is some device preventing the herb material from sticking to the knives. Thus it could meet the requirements of GMP.
主要技術參數 Main technical parameter
型號
Type |
生產能力
Capacity
(kg/h) |
切刀數量
Knife number |
切片厚度
cut herb
thickness
(mm) |
電機功率
motor
(KW) |
外形尺寸
dimension
(mm) |
整機重量
weight
(kg) |
|
QL400 |
200-600 |
1 |
2-6 |
4 |
1196x700x1000 |
500 |
|
QL600 |
300-800 |
1 |
2-6 |
7.5 |
1830x1400x1220 |
660 |
